Name: i06_Bathy_NCRO_20190311_LittleMandeville

Display Field: FEATURE_CLASS_NAME

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>The California Department of Water Resources (CA-DWR), North Central Region Office (NCRO), Bathymetry Data Collection Section, conducted a bathymetric survey of Little Mandeville Island for the Bay Delta Office (BDO). The main purpose of the data is to replace outdated and inaccurate data, improve innudation mapping throughout the Delta and help with the evaluation of restoration proposals nearby. This dataset is from kayak-mounted singlebeam sonar for the northwest corner of the Island and is meant to supplement a grid of multibeam strips for the remainder of the Island. </SPAN><SPAN><SPAN>The data were collected in NAD83 (California State Plane Zone III coordinate system) and NAVD88 datums.</SPAN></SPAN></P><P><SPAN>• Survey Dates: March 11, 2019 </SPAN></P><P><SPAN STYLE="font-size:12pt">• Instrumentation: Singlebeam echo sounder with Inertially-Aided Post-Processed Kinematic (IAPPK) GPS procedures</SPAN></P><P><SPAN>• Point Spacing: about 1 Foot</SPAN></P><P><SPAN>• Horizontal Units: US Foot</SPAN></P><P><SPAN>• Vertical Units: US Foot</SPAN></P><P><SPAN STYLE="font-size:10pt">• Related datasets: Little Mandeville Island, April 2019 -- multibeam grid; Little Mandeville Island, June 2020 -- multibeam data for levee breaches</SPAN></P></DIV></DIV></DIV>

Copyright Text: California Department of Water Resources, Division of Regional Assistance, North Central Region Office, Hydrography and Technical Support Section.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.35332653724E7
YMin: 4581240.376599997
XMax: -1.3532251603500001E7
YMax: 4581950.670599997
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Class Breaks Renderer:
Field: Z
Min. Value: -9.223372036854776E18
ClassBreakInfos:
• Class Maximum Value: 9223372036854775807
  Label: N/A
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [130, 130, 130, 255]
  Size: 2.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Date_ ( type: esriFieldTypeDate, alias: Date, length: 8 )
• Time_ ( type: esriFieldTypeString, alias: Time, length: 1073741822 )
• X ( type: esriFieldTypeDouble, alias: X )
• Y ( type: esriFieldTypeDouble, alias: Y )
• Z ( type: esriFieldTypeDouble, alias: Z )
• SOURCE ( type: esriFieldTypeString, alias: SOURCE, length: 50 )
• LAST_MODIFIED_DATE ( type: esriFieldTypeDate, alias: LAST_MODIFIED_DATE, length: 8 )
• MODIFIED_BY ( type: esriFieldTypeString, alias: MODIFIED_BY, length: 50 )
• DATE_DATA_REFERS_TO ( type: esriFieldTypeDate, alias: DATE_DATA_REFERS_TO, length: 8 )
• DATA_FORMAT ( type: esriFieldTypeString, alias: DATA_FORMAT, length: 50 )
• DATA_EQUIPMENT_TYPE ( type: esriFieldTypeString, alias: DATA_EQUIPMENT_TYPE, length: 50 )
• DATE_STARTED ( type: esriFieldTypeDate, alias: DATE_STARTED, length: 8 )
• DATE_COMPLETED ( type: esriFieldTypeDate, alias: DATE_COMPLETED, length: 8 )
• FEATURE_CLASS_NAME ( type: esriFieldTypeString, alias: FEATURE_CLASS_NAME, length: 200 )
• SURVEY_REPORT ( type: esriFieldTypeString, alias: SURVEY_REPORT, length: 200 )
• COMMENTS ( type: esriFieldTypeString, alias: COMMENTS, length: 500 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
