Name: i06_Bathy_NCRO_20180314_CliftonCourtForebay

Display Field: Feature_Class_Name

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>The California Department of Water Resources (CA-DWR), North Central Region Office (NCRO), Bathymetry Data Collection Section, conducted a bathymetry survey of Clifton Court Forebay (CCF) at the request of the Bay Delta Office and Delta Field Division. DWR conducted a single-beam sonar survey in CCF in March 2018. This survey was intended as a more limited assessment of change by replicating selected transects from a more comprehensive 2016 survey. The shallow regions of Clifton Court Forebay were sampled to determine general bed elevation trends since 2016, and to determine whether further measurements are necessary. The singlebeam field survey was completed on March 14, 2018. A separate, February 2018, multibeam dataset of the apron and scour hole is available. </SPAN><SPAN>The original field survey data were positonally corrected using Real-Time Kinematic (RTK)GPS. </SPAN><SPAN>The original field survey data were collected in NAD83 (California State Plane Zone III coordinate system) and NAVD88 datums.</SPAN></P><P><SPAN>• Horizontal Units: US Foot</SPAN></P><P><SPAN>• Vertical Units: US Foot</SPAN></P></DIV></DIV></DIV>

Copyright Text: California Department of Water Resources, Division of Integrated Regional Water Management, North Central Region Office, Hydrography and Technical Support Section.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.35356644471E7
YMin: 4554174.3928999975
XMax: -1.35314656373E7
YMax: 4558812.0031
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Class Breaks Renderer:
Field: Z
Min. Value: -9.223372036854776E18
ClassBreakInfos:
• Class Maximum Value: 9223372036854775807
  Label: N/A
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [130, 130, 130, 255]
  Size: 2.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• X ( type: esriFieldTypeDouble, alias: X )
• Y ( type: esriFieldTypeDouble, alias: Y )
• Z ( type: esriFieldTypeDouble, alias: Z )
• Source ( type: esriFieldTypeString, alias: Source, length: 25 )
• Last_Modified_Date ( type: esriFieldTypeDate, alias: Last_Modified_Date, length: 8 )
• Modified_By ( type: esriFieldTypeString, alias: Modified_By, length: 25 )
• Date_Data_Refers_To ( type: esriFieldTypeDate, alias: Date_Data_Refers_To, length: 8 )
• Data_Format ( type: esriFieldTypeString, alias: Data_Format, length: 25 )
• Data_Equipment_Type ( type: esriFieldTypeString, alias: Data_Equipment_Type, length: 40 )
• Date_Started ( type: esriFieldTypeDate, alias: Date_Started, length: 8 )
• Date_Complete ( type: esriFieldTypeDate, alias: Date_Complete, length: 8 )
• Feature_Class_Name ( type: esriFieldTypeString, alias: Feature_Class_Name, length: 50 )
• Survey_Report ( type: esriFieldTypeString, alias: Survey_Report, length: 50 )
• Comments ( type: esriFieldTypeString, alias: Comments, length: 100 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
