Name: i08_GeologicUnits_SacramentoValley

Display Field: Lithology

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This data set is a series of polygons denoting the geologic units mapped in USGS Publication MF-1790, "Geologic Map of the Late Cenozoic Deposits of the Sacramento Valley and Northern Sierran Foothills, California" (Helley and Harwood,1985). This data set was created by scanning the five- original sheets from USGS Publication MF-1790 (Helley and Harwood, 1985), the five sheets were georeferenced individually and the geologic information was digitized using AutoCAD 2006. The accuracy of the digitized lines was deemed to be within acceptable error tolerances, with the digitized lines accurately matching the original drafted lines in USGS Publication MF-1790 (Helley and Harwood, 1985). In general, the width of the contact lines on the paper copy, accounting for scale, ranged up to about 20 meters (66 feet). During the original digitization, minor topological mistakes (such as identical rock units on both sides of a lithologic contact or unclosed polygons) and omissions (such as unidentified lithologic units) were applied according to the best available knowledge. Comparisons were made between the original mylar and colorized field sheets (as available), in addition to the Geologic Map of the Battle Creek Fault Zone, Northern Sacramento Valley, California (USGS Map MF-1298, 1981), the Geologic Map of the Chico Monocline and Northeastern Part of the Sacramento Valley, California (USGS Miscellaneous Investigations Series Map I-1238, 1981), the Geologic Map of the Red Bluff 30' X 60' Quadrangle, California (USGS Geologic Investigation Series Map I-2542, 1995), and the Geologic Map of the Whitmore Quadrangle, California (Geologic Quadrangle Map GQ-993) . The correlation and description of geologic units were excerpted from USGS Publication MF-1790m (Helley and Harwood, 1985).</SPAN></P></DIV></DIV></DIV>

Copyright Text: Department of Water Resources, Northern Region Office, Groundwater and Geological Investigations Section. Originator: Jonathan Mulder. Updates: Nate Cheshier Helley, E.J., and Harwood, D.S., 1985, Geologic map of the late Cenozoic deposits of the Sacramento Valley and northern Sierran foothills, California: U.S. Geological Survey Miscellaneous Field Studies Map MF-1790, 24 p., scale 1:62,500, 5 sheets.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.36645951347E7
YMin: 4614791.294
XMax: -1.3497607547E7
YMax: 4975520.139899999
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [130, 130, 130, 0]
Outline:
Style: esriSLSSolid
Color: [0, 0, 0, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Lithology ( type: esriFieldTypeString, alias: Lithology, length: 1073741822 )
• SheetNumber ( type: esriFieldTypeString, alias: HelleyHarwoodSheetNo, length: 255 )
• Date ( type: esriFieldTypeDate, alias: Date, length: 8 )
• Source ( type: esriFieldTypeString, alias: Source, length: 255 )
• DateEdited ( type: esriFieldTypeString, alias: DateEdited, length: 255 )
• EditedBy ( type: esriFieldTypeString, alias: EditedBy, length: 255 )
• Comments ( type: esriFieldTypeString, alias: Comments, length: 255 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SHAPE.STArea() ( type: esriFieldTypeDouble, alias: SHAPE.STArea() )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
